In today’s hyper-connected world, wireless connectivity is no longer a luxury. It has become a basic expectation. Compact connected devices are shaping the future of digital infrastructure. These include wearable health sensors, smart lighting systems, industrial control nodes, and logistics trackers.

However, engineers face several challenges when designing small, battery-powered devices. They must balance power consumption, cost, board space, certification, and system complexity. Each of these factors directly affects product feasibility.

A low-energy Bluetooth SoC solves many of these challenges. It integrates wireless communication, processing, memory, power management, and peripheral interfaces into a single chip. This approach reduces complexity and improves efficiency.

The SoC supports Bluetooth Low Energy (BLE) up to version 5.1. It also includes advanced power optimization features. These capabilities allow developers to build cost-effective and energy-efficient products for medical, consumer, industrial, and smart infrastructure applications.

Built for Extreme Power Efficiency

This SoC runs directly on a single 1.5V battery cell. This design eliminates the need for multi-cell battery configurations. As a result, it reduces system complexity and saves space.

Advertisement

In low-power devices like remote controls and wearable trackers, battery life matters more than processing power. The SoC addresses this need with an efficient power management system. It operates with input voltages between 1.8V and 3.6V. It also supports USB input ranging from 4.5V to 5.5V.

The built-in battery monitor detects low-voltage conditions. It identifies brownout situations and ensures stable operation. The integrated LDO and DC-DC regulators optimize voltage levels across different operating modes.

The SoC consumes about 5mA in active mode at 3V. In sleep mode with SRAM retention, it uses around 1µA. Under external wake-up conditions, it reduces consumption to as low as 0.4µA. These low power levels allow devices to run for months or even years on a small coin cell battery.

Compact Design for Small Devices

Modern IoT and wearable devices demand compact designs. This SoC comes in extremely small package options. These include a 1.6 × 2.0 × 0.5 mm WLCSP and a 3 × 3 × 0.55 mm QFN24.

The WLCSP package suits ultra-small applications like medical patches, smart rings, and sensor nodes. Even in its smallest version, the SoC includes five GPIO pins. The QFN version supports up to twelve GPIOs for expanded functionality.

Advertisement

This high level of integration reduces the bill of materials. It also simplifies PCB layout. The embedded RF matching circuit removes the need for many external components. Designers can even eliminate inductors in some cases, which further lowers system cost.

Reliable Wireless Performance

The SoC supports Bluetooth Low Energy up to version 5.1. It works seamlessly with modern smartphones, tablets, and medical devices. BLE 5.x improves range, speed, and coexistence. These improvements enhance performance in different environments.

The transceiver operates at 1 Mbps and 2 Mbps. It also supports Long Range mode and 250 kbps under IEEE 802.15.4. In addition, it supports ANT and ANT+ protocols. These features make it suitable for fitness and health applications.

The receiver achieves high sensitivity levels. It reaches about -97 dBm for BLE and -100 dBm for IEEE 802.15.4. The transmitter delivers up to +10 dBm output power. This combination ensures strong and stable communication over longer distances.

Because of this performance, the SoC works well in smart homes, industrial networks, and transportation systems.

Advertisement

Integrated Processing and Memory

The SoC includes a built-in microcontroller with a 32-bit processor. It operates at speeds up to 48 MHz. The design focuses on energy efficiency while maintaining strong performance.

The memory system includes 64 kB of Flash and 32 kB of SRAM. The SRAM supports retention, which helps preserve data during low-power modes. This setup allows developers to run BLE stacks, applications, and peripheral controls efficiently.

The chip also includes one-time programmable memory. Developers can use it for secure configuration storage. By combining processing, memory, and RF functions into one chip, the SoC reduces the need for external components and simplifies development.

Advanced Power Management

Efficient energy use remains critical for battery-powered devices. This SoC provides multiple power-saving modes, including active, idle, and sleep states.

It supports fast wake-up while maintaining SRAM data. External triggers can also activate the system when needed. This feature works well for sensor-based applications.

Advertisement

The integrated DC-DC converter improves efficiency during high-current operation. The LDO regulator maintains stable power during low-power modes. Together, these features create a flexible and efficient power system.

Battery monitoring and brownout protection further improve reliability. These features ensure consistent performance in medical and industrial applications.

Flexible Interfaces for System Design

The SoC supports a wide range of digital and analog interfaces. Developers can configure GPIO pins for different applications. The built-in 16-bit PWM supports motor control, LED dimming, and waveform generation.

Communication interfaces include SPI, I2C, UART, and USB 2.0. These allow easy integration with sensors, displays, and external processors. The USB interface also supports firmware updates and diagnostics.

On the analog side, the SoC includes a 14-bit ADC and an internal temperature sensor. These features support environmental monitoring, battery management, and wearable diagnostics without extra components.

Advertisement

Simplified RF Design

RF design often adds complexity and cost. This SoC simplifies the process by integrating the RF matching circuit. Designers no longer need large external matching networks.

The chip supports inductor-free operation in some designs. This reduces the number of passive components and lowers assembly costs.

Developers can also use an optional 32 kHz crystal for precise timing. Alternatively, they can rely on internal resources depending on application needs.

This level of integration reduces development time and accelerates product launches.

Certification and Compliance

Manufacturers must meet regional standards when launching wireless products. This SoC meets major global certifications, including ETSI, FCC, and ARIB.

Advertisement

These certifications simplify product approval. They reduce both time and cost during regulatory processes. The SoC also complies with RoHS standards and uses a lead-free design.

This built-in compliance supports companies that target global markets.

Wide Range of Applications

This SoC supports a variety of applications due to its low power, compact size, and strong performance.

It enables small Bluetooth accessories for smartphones and tablets. It also powers RF remote controls with long battery life. In fitness and health devices, it supports BLE and ANT connectivity.

Wearable devices benefit from its lightweight and efficient design. Smart home systems use it for automation and mesh networking. Industrial systems rely on its RF performance and sensor capabilities.

Advertisement

Healthcare applications use it for remote monitoring and portable diagnostics. Consumer electronics manufacturers value its low cost and easy integration.

Driving Future IoT Innovation

As IoT continues to grow, developers must balance performance, cost, and power efficiency. This SoC helps achieve that balance.

It combines wireless communication, processing, memory, and power management into one compact solution. This allows developers to focus on innovation instead of hardware complexity.

Its low power consumption, multi-protocol support, and reduced component count make it ideal for scalable IoT systems.

Conclusion

The ultra-low-cost BLE SoC offers a practical and forward-looking solution for wireless design. It combines BLE 5.1 support, compact size, efficient power management, and flexible interfaces in a single chip.

Advertisement

Manufacturers can use it to build medical devices, wearables, smart infrastructure, and consumer electronics. It delivers strong performance while keeping costs and power usage low.

As connected devices become smaller and more efficient, integrated SoC platforms like this will play a key role in shaping the future of IoT innovation.
